Low-level codecs

Under the media front, every codec and container is a module of its own: h264, hevc, vp9, aac, ac3, mp3, opus, mp4, mkv, gif, webp, filter and gpu. Use them when you want to drive the decode yourself. The API reference lists every type.

Decode an MP4’s H.264 track

use pito_codecs::{h264, mp4};

let file = mp4::Reader::open("clip.mp4")?;
let video = file.video().ok_or("no video track")?;
let track = &file.tracks[video];
let mut decoder = h264::Decoder::with_extradata(&track.extradata().unwrap_or_default())?;
let mut frames = Vec::new();
for index in 0..track.samples.len() {
    frames.extend(decoder.decode(&file.packet(video, index)?)?);
}
frames.extend(decoder.flush()?);

decoded 600 frames, 1920x1080, in 0.79 s

Each Frame holds three planes (planes[0] luma, then the two chroma planes, each with its stride), a format such as PixelFormat::Yuv420p8, and a pts in its time_base. The decoder hands frames out in display order and may hold some back until later packets arrive; flush returns the rest. media::to_rgba turns a frame into RGBA.

Encode H.264

use pito_codecs::h264::{Encoder, EncoderConfig};
use pito_codecs::media::Rate;

let mut encoder = Encoder::new(EncoderConfig {
    width: 1920,
    height: 1080,
    fps: (60_000, 1001),
    rate: Rate::Crf(20),
    ..Default::default()
})?;
let avcc = encoder.avcc();
for frame in &frames {
    for packet in encoder.encode(frame)? {
        sink.write(&packet.data);
    }
}
for packet in encoder.flush()? {
    sink.write(&packet.data);
}

encoded 120 frames into 120 packets, 1072669 bytes, avcC 48 bytes, in 1.37 s

sink stands for wherever the packets go. EncoderConfig also sets the profile, the preset (speed, balanced or quality), the gop, the number of b_frames, the threads, and the bitstream: length-prefixed for MP4 with avcc() as its configuration (the default), or Bitstream::AnnexB for a raw .h264 file. Rate is Crf(n), Qp(n), Bitrate(kbps) (constant) or Vbr { kbps, max_kbps }.

Decode on the GPU

use pito_codecs::gpu::{self, HwDecoder};
use pito_codecs::media::Codec;

let mut decoder = HwDecoder::new(Codec::H264, &track.extradata().unwrap_or_default())?;
let frames = decoder.decode(&file.packet(video, 0)?)?;

HwDecoder::new fails when no GPU decoder for the codec is there, so check gpu::available() first or fall back to the CPU decoder; HwEncoder is its encoding twin. The GPU guide lists what each system has.

GIF

use pito_codecs::gif::{self, Dither, EncodeOptions};

let data = gif::encode(&stills, &vec![4; stills.len()], EncodeOptions {
    colors: 128,
    dither: Dither::Ordered,
    ..Default::default()
})?;
let back = gif::decode(&data)?;

gif: 30 frames, 1669056 bytes, 38.3 ms
gif decoded back: 30 frames

Frames are Rgba, delays are in hundredths of a second. The encoder builds Oklab palettes (global or per frame), dithers with ordered or Floyd-Steinberg patterns, and stores only the changed area of each frame; gif::Encoder takes frames one at a time.

WebP

use pito_codecs::webp::{self, AnimEncoder, Options};

let still = webp::encode(&image, &Options::lossless())?;
let mut anim = AnimEncoder::new(480, 270, Options::lossy(75.0), 0)?;
for frame in &stills {
    anim.add(frame, 40)?;
}
let data = anim.finish()?;
let info = webp::info(&data)?;

webp: 532888 bytes, 64.8 ms
webp info: 480x270, 30 frames, animated true

Lossless (VP8L) and lossy (VP8) stills and animations, with alpha; durations are in milliseconds, and the last argument of AnimEncoder::new is the loop count (0 loops forever). webp::decode and webp::decode_animation read them back, bit-exact with libwebp.
