Your first scene

A recipe is one TOML file. This one is a desk with a box and a brass ball, a camera, a sun and a sky.

Write the recipe

Save this as desk.toml:

manfred = 1
name = "desk"

[output]
glb = "desk.glb"
sidecar = "desk.json"
sidecar_dialect = "facts"

[[object]]
name = "top"
kind = "plane"
size = [1.2, 0.8]
material = "oak"

[[object]]
name = "box"
kind = "box"
at = [-0.15, 0.05, 0.0]
size = [0.2, 0.1, 0.14]
bevel = { width = 0.01, segments = 4 }
material = "blue"

[[object]]
name = "ball"
kind = "sphere"
at = [0.15, 0.05, 0.05]
radius = 0.05
material = "brass"

[[camera]]
name = "main"
position = [0.0, 0.35, 0.7]
target = [0.0, 0.03, 0.0]
fov_y_deg = 35.0

[sun]
model = "authored"
toward = [-0.45, 0.82, 0.35]
color = [1.0, 0.92, 0.82]
irradiance = 2.2

[sky]
kind = "analytic"
intensity = 0.9

[materials.oak]
family = "wood"
base = [0.42, 0.28, 0.16]
roughness = 0.55

[materials.blue]
family = "lacquer"
base = [0.08, 0.2, 0.5]
roughness = 0.3

[materials.brass]
family = "metal"
base = [0.85, 0.66, 0.35]
roughness = 0.3
metalness = 1.0

Units are metres, Y is up, angles are degrees and colours are linear RGB from 0 to 1. manfred = 1 is the schema version; the recipe has every key.

Check it

manfred check desk.toml

A valid recipe prints nothing and exits 0. A problem is printed at its line, and the command exits 1. With a negative radius on the ball:

$ manfred check desk.toml
desk.toml:27: object[ball].radius: expected a number above 0

Build it

manfred build desk.toml --out out

out/desk.glb
out/desk.json

manfred build writes the GLB and the JSON sidecar the [output] table names, here into out/ because of --out. It needs no GPU and no window, and takes a few milliseconds. The build is deterministic: the same recipe gives the same bytes on any machine.

The sidecar holds what the GLB cannot: the cameras, the sun and the sky, in the facts dialect (file formats).

Draw it live

manfred shot desk.toml --camera main --size 800x500 --out desk.png

manfred shot draws one still through the main camera with the engine’s live renderer, headless, and prints desk.png.

Path-trace it

manfred render desk.toml --camera main --size 800x500 --out desk-traced.png

manfred render: 800x500, 37.9 samples a pixel on average, 64 at most of 64, threshold 0.01, seed 0: 36 submissions, the longest 10.29 ms, 177 ms on the GPU

The path written goes to stdout and the summary to stderr. Path-trace a still covers drafts, crops and the other formats.

Open it in the window

manfred gui desk.toml

Click the ball, drag the gizmo’s arrow, and the recipe file changes under you. Arrange a scene in the window says how.
